Clip-on Grounding Kit


  • Place of Origin: China (Mainland)
  • Brand Name: Telsto
  • Grounding Strap: 05mmT2 copper
  • Jumper Ring: SUS304
  • Copper Bolt: T2 copper
  • Cable Length: 6AWG or according to your requirements
  • Installation Hard wares: SUS304
  • Touch Resistance: ≤10 mΩ
  • Insulation Resistance: ≥ 500MΩ
  • Resists Trike Electricity: ≥70 KA
  • Weatherproofing Kit: Included
  • Description

    Clip-on grounding kit are an advanced type for coaxial cable grounding, providing an easy installation as well as dependable protection of coaxial cable system. The designed clip design and pre-formed strap allow the clip-on ground kits to be easily slipped over the coaxial cable's outer conductor.

    The latch was optimized to provide a secure fix maximizing performance by ensuring proper contact surface area and pressure.

    Framework Grounding Kit

    Framework type grounding kit is compact design for outdoor coaxial cable's (corrugated or braid) grounding. With Tinned copper strip & butyl seal, framework type grounding kit offers Quick installation, good waterproofing & cost efficiency.

    Wire Grip Grounding Kit (4)

    Standard Grounding Kit

    This type of grounding kit can be used for 1/4 in and 3/8 in corrugated & braided coaxial cable. It was designed according to Commscope (Andrew) GK-242948. Features of this product are installed by the cable ties. It allows it can be used for at least two types of coaxial cable.

    Wire Grip Grounding Kit (1)

    Small Universal Grounding Kit

    Telsto Small Universal Grounding Kit is designed according to Commscope (Andrew) GK-SUNV. It's small and light, can be used for coaxial cable under 0.6 in.

    Wire Grip Grounding Kit (2)

    Bolt-on Grounding Kit

    Telsto Bolt-on Grounding Kits are used for 3/8" in corrugated & braided coaxial cable. It requires  wrench when installing. That makes it perfect contact area. Moreover, we can make it for different cable.

    Wire Grip Grounding Kit (5)

    Universal Grounding Kit

    Universal Grounding Kit can be used for all coaxial cable. It consist of a long thick copper strap. You can cut it according to the coaxial cable you will used for.

    Wire Grip Grounding Kit (7)
