Waterproof ftth armored patchcord 3m duplex om3 jumper

Waterproof ftth armored patchcord 3m duplex om3 jumper sc apc lc upc fc st e2000 mtp mpo pigtal cable fiber optic patch cord


  • Type: fiber patch cord
  • Model Number: patch cord outdoor
  • Brand Name: TELSTO
  • Network Wireless: Lan, Wired LAN, wifi, 4g, 3G
  • Product name: lc/upc-lc/upc fc/upc unit boot sc patch cord unitboot
  • Size: 3.0mm 2.0mm lszh g657a2 g657a1 g652d
  • Length: 1m 1.5m 2m 5m 7m 10m 15mtr 25m 30m
  • Model: mpo-mpo lc-sc lc/upc sc/upc -sc/upc sc apc to sc upc
  • Origin: Shanghai
  • Description

    Telsto Fiber Optic Patch Cords are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. Refer to the diagram above for dimensional information. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic/phosphor bronze alignment sleeves and a precision moulded polymer housing provides consistent long-term mechanical and optical performance.

    Waterproof ftth armored patchcord 3m duplex om3 jumper  (2)

    Application

    1; Telecommunication networks;

    2; Local area networks; CATV;

    3; Active device termination;

    4; Data center system networks;

    Waterproof ftth armored patchcord 3m duplex om3 jumper  (1)

    Products Description

    Type Standard,Master
    Style LC,SC,ST,FC.MU,DIN,D4,MPO, SC/APC,FC/APC,LC/APC.MU/APC
    Duplex MTRJ/Female, MTRJ/Male
    Fiber Type 9/125 SMF-28 or equivalent (Singlemade) OS1
    50/125, 62.5/125 (Multimode) OM2&OM1
    50/125, 10G (Multimode) OM3
    Cable Type Simplex, Duplex (Zipcord)

    Φ3.0mm, Φ2.0mm, Φ1.8mm
    Φ1.6mm PVC or LSZH
    Φ0.9mm, Φ0.6mm buffered fiber PVC or LSZH

    Polishing Manner UPC,SPC,APC (8°& 6°)
    Return Loss

    (For Singlemode)

    UPC ≥ 50dB

    SPC ≥ 55dB
    APC ≥ 60dB (typ.65dB)

    Tested by JDS RM3750

    Insertion Loss ≤ 0.1dB (For Singlemode Master)
    ≤ 0.25dB (For Singlemode Standard)
    ≤ 0.25dB (For Multimode)
    Tested by JDS RM 3750
    Operating temperature -40℃ to 85℃
    Repeatability ±0.1dB
    Geometry Requirement

    (For Singlemode)

    Ferrule Endface Radius

    7mm ≤ R ≤ 12mm (For APC)
    10mm ≤ R ≤ 25mm (For Standard)
    Apex Offset ≤ 30 μm (For Master)
    Apex Offset ≤ 50 μm (For Standard)
    Undercut -50nm ≤ U ≤ 50nm
    Tested by DORC ZX-1
