Telsto Series Gel Seal Closure

Model Number: TEL-GSC-1/2-7/8

Brand Name: Telsto

Place of Origin: China (Mainland)

Application: Antenna Connector Closure

Use: Weatherproofing Kit

Market: Wireless Cell Site

Coax Connection: Antenna or In-line Connections

Color: Black

Material: PP/ABS/TBE

Sealing Class: IP68

Send email to us

Description

Telsto Gel seal closure (Weather shields) is a weatherproofing system for sealing coaxial cable jumper-to-feeder, jumper-to-antenna and grounding kit connectors exposed to the outside environment. The housing contains an innovative gel material and provides an efficient moisture block effectively water-proofing the connectors. The ease of installation and the long term protection makes it a reliable and cost effective sealing solution for outside plant cables and connectors.

*IP rating 68

*Certificated materials: housing—PC+ABS; gel--TBE

*Wide temperature range: -40°C/+ 60°C

*Quick and easy to install

*No tape, mas tics or tools required for installation and removal

*Easily removable and re-usable

Telsto Gel seal closure (Weather shields) (2)

Gel Seal Closure
Model	TEL-GSC-1/2-7/8
Function	Gel Seal Closure for 1/2"jumper to 7/8"feeder
Material	PC+SEBS
Size	L195mm,W88mm,H55mm
Input	1/2"jumper(13-17mm)
Output	7/8"feeder(27-29mm)
Net Weight	256g
Life/duration	More than 10 years
Corrosion and ultraviolet resistance	H2S,passed ultraviolet test
Ice-snow resistance	up to 100mm,no water leakage, no shape change
Waterproof level	IP68
Fireproof level	HB
Rainstorm resistance	100E 150mm/h
