Standard Grounding Kit


  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: Telsto
  • Model Number: Standard Grounding Kit
  • Product Line: Grounding Kits
  • Product Type: Standard Grounding Kit
  • Current handing: >50KA
  • Contact resistance: <4mΩ
  • Grounding wire length: According to customer requirements
  • Grounding wire size: AW6 / 16mm2
  • Inner contact material: copper
  • Waterproofing: IP67
  • Cable size: 1/4" 3/8"
  • OEM: accepted
  • Description

    · Compact structure

    · Faster and easy installation

    · No loose parts

    Description

    Apply with 1/4 in and 3/8 in corrugated & braided coaxial cable

    Standard Grounding Kit (3)
    Standard Grounding Kit (2)

    Jumper cables offer outstanding electrical performance along with high durability for tight routing and superior environmental sealing for ling life reliability.

    Jumper cables are used in areas that require extremely small bending radius such as between main feeders and antennas or between main feeders and RF equipment. Jumper cables are designed and produced to have features as below

    Types

    Grounding kits protect BTS against lighting, Telsto grounding kits are fast-installed, easy and error-free with self-securing grounding strap. Grounding kit body facilitates a proper attachment to the coaxial cable, ensuring that the performance of the coaxial cable is not being compromised. The tin plated copper clip provides a secure, low resistance connection to the cable outer conductor and the field-install able lug allows for custom ground wire lengths.

    *Various types

    *Fast installation

    *Perfect lighting protection

    *Total weather proofing

    Product  Description Part No.
    Click-on Type

    including butyl and electric tape

    for  1/4" coaxial cable   TEL-GK-C-1/4
    for  1/2" coaxial cable   TEL-GK-C-1/2
    for  7/8" coaxial cable   TEL-GK-C-7/8
    for  1-1/4"coaxial cable   TEL-GK-C-5/4
    for  1-5/8" coaxial cable   TEL-GK-C-13/8
    Framework Type for  1/4" coaxial cable   TEL-GK-F-1/4
    for  1/2"coaxial cable   TEL-GK-F-1/2
    for  7/8" coaxial cable   TEL-GK-F-7/8
    for  1-1/4"coaxial cable   TEL-GK-F-5/4
    for  1-5/8" coaxial cable   TEL-GK-F-13/8
    Universal Type

    including butyl and electric tape

    for  1/4" coaxial cable   TEL-GK-U-1/4
    for  1/2" coaxial cable   TEL-GK-U-1/2
    for  7/8"coaxial cable   TEL-GK-U-7/8
    for  1-1/4"coaxial cable   TEL-GK-U-5/4
    for  1-5/8" coaxial cable   TEL-GK-U-13/8
