Leaky Feeder Hanger Cable Clamp
The feeder clamp is a fixed device used for the communication base stations, repeaters, indoor coverage systems, wireless paging and microwave communication systems.
And Leaky Feeder Cable Hanger Cable Clamp is a Self-locking hanger, used to fix power cable and fiber cable at the same time.
Leaky Feeder Cable Hanger Cable Clamp Features
The clamp is designed to secure 1 leaky cable.
Good impact-resistance and tear-resistance.
Operating temperature:-40℃+80℃
Insert 1 cable hanger every 1m.
Flammability Test Method:UL94
Technical Data
| Product Name | Leaky Feeder Cable Hanger Cable Clamp |
| Item No. | TEL-LC158 |
| Type | Round base |
| Clamp Class | Self-Locking Hanger |
| Plastic Material | Polypropylene (PP)/PA66 |
| Metal Material | Self-Locking Hanger |
| Clamp Stack | Single Fold Stack |
| Match Cable | 7/8",1-1/4",1-5/8" Leaky Cable |
Leaky Feeder Hanger Cable Clamp Application
Apply to installing radiating cables in galleries and tunnels with or without spacers. The installation is very simple and quick.
Application Scope: 1/4" S (4-7mm) clamp, 1/4" (7-9mm) clamp, 3/8" (9-11mm) clamp, 1/2" S (12-14mm) clamp, 1/2" (15-17mm) clamp, 5/8" (21-23mm) clamp, 7/8" (27-29mm) clamp, 1-1/4" (38-40mm) clamp, 1-5/8" (49-51mm) clamp
Package
MOQ: Flexible, OEM orders acceptable.
Packing details: Plastic/carton box, then seaworthy plywood case, or as per request.
Shipping method: By express, by air or by sea or as request.
Shipping port: Shanghai, Qingdao, Tianjin or as per request.
Shipping time: according to order quantity.
