Outdoor SC LC Fiber Optical Patch Cord Jumper Fibra Optica Patch Cord

Outdoor SC LC Fiber Optical Patch Cord Jumper Fibra Optica Patch Cord


  • Brand Name: Telsto
  • Application: Audio & Video, CATV HFC
  • Type: SC/LC/ST/FC
  • Mode: SingldeMode
  • Jacket: PVC/LSZH
  • Ferrule end face: PC/UPC
  • Fiber counts: Simplex/Duplex
  • Cable length: 1.5/3/5/10/20m or customize
  • CABLE: Fiber Optic patch cord
  • CABLE: coaxial drop cable
  • Certification: ISO9001
  • Origin: Shanghai
  • Description

    Telsto Fiber Optic Patch Cords are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. Refer to the diagram above for dimensional information. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic/phosphor bronze alignment sleeves and a precision moulded polymer housing provides consistent long-term mechanical and optical performance.

    Features

    (1) Ceramic Ferrule;
    (2) High return loss;
    (3) Low insertion loss;
    (4) Good repeatability and and exchangeability;
    (5) Excellent Polished and 100% tested;
    (6) Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard.

    Application

    1. Local Area Network (LAN)
    2. Data communication network
    3. Telecommunication optical transmission network
    4. Optical access network(OAN)
    5. Active device termination
    6. Fiber optics data transmission(FODT)
    7. Test Equipment
    8. CATV
    9. ATV

    Performance index

    Item SM(Single Mode) MM(Multimode)
    Fiber Cable Type G652/G655/G657 OM1 OM2/OM3/OM4
    Fiber Diameter (um) 9/125 62.5/125 50/125
    Cable OD (mm) 0.9/1.6/1.8/2.0/2.4/3.0
    Endface Type PC UPC UPC UPC UPC
    Typical Insertion Loss (dB) <0.2 <0.15 <0.2 <0.1 <0.1
    Return Loss (dB) >45 >50 >60 /
    Insert-pull Test (dB) <0.2 <0.3 <0.15
    Interchangeability (dB) <0.1 <0.15 <0.1
    Anti-tensile Force (N) >70
    Temperature Range (℃) -40~+80
    Outdoor SC LC Fiber Optical Patch Cord Jumper Fibra Optica Patch Cord (1)
