Clip-on grounding kit 12’’
Clip-on ground kits are an advanced type for coaxial cable grounding, providing an easy installation as well as dependable protection of coaxial cable system. The designed clip design and pre- formed strap allow the clip-on ground kits to be easily slipped over the coaxial cable’s outer conductor.
The latch was optimized to provide a secure fix maximizing performance by ensuring proper contact surface area and pressure.
Contact: high quality copper strap;
Grounding clamp: per-formed copper strap;
Grounding / earthing cable:16mm2 or 25mm2 BV or BVR copper wire for earthing to buss bar;
Copper lugs: 16-8, 25-8 tin plated copper lugs to connect to grounding bar;
Installation accessories: stainless steel 304.
Application:
Grounding for following indoor / outdoor cable;
1, Telecom cable
2, Fiber cable
3,Coaxial cable
4, Feeder cable
5, Hybrid cable
6, Corrugated cable
7, Smooth cable
8, Braid cable
| Product | Description | Part No. |
| Click-on Typeincluding butyl and electric tape | for 1/4" coaxial cable | TEL-GK-C-1/4 |
| for 1/2" coaxial cable | TEL-GK-C-1/2 | |
| for 7/8" coaxial cable | TEL-GK-C-7/8 | |
| for 1-1/4" coaxial cable | TEL-GK-C-5/4 | |
| for 1-5/8" coaxial cable | TEL-GK-C-13/8 |
