400G-QSFP-DD-FR4-CWDM4-2KM

Product Name: 400G QSFP-DD SR8 850nm 100M MPO MMF Module

Type: QSFP-DD (Quad Small Form-Factor Pluggable Double Density)

Data Rate: 400 Gigabit per Second (Gbps)

Interface: QSFP-DD Connector

Protocol: SR8 (Short Reach 8-lane)

Wavelength: 850nm

Fiber Type: Multi-mode Fiber (MMF)

Transmission Distance: Up to 100 Meters (M)

Connector Type: MPO (Multi-fiber Push On)

Operating Voltage: 3.3V

Power Consumption: Varies by Manufacturer and Configuration

Place of Origin: Shanghai, China (Mainland)

Brand Name: Telsto

Send email to us

Description

400G QSFP-DD SR8 850NM 100M MPO MMF

400GBASE-SR8 module supports link lengths of up to 100m over multimode fiber (MMF) with MTP/MPO-16 connector. It is compliant to IEEE 802.3bs protocol and 400GAUI-8/CEI-56G-VSR-PAM4 standard. The 400 Gigabit Ethernet signal is carried over eight wavelengths. Multiplexing and demultiplexing of the eight wavelengths are managed within the device.

Built-in Inphi DSP Chip, Max. Power Consumption 10W

Tested in Targeted Switches for Superior Performance, Quality, and Reliability

Compliant with QSFP-DD MSA CMIS Rev4.0, OIF 56G PAM4

Support Real-time Configuration

Hot Pluggable QSFP-DD Form Factor

High-speed Electrical Compliant to IEEE 802.3cd

8x50G PAM4 Retimed 400GAUI-8 Electrical Interface

Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
