24 COER ODF Fiber Optic PATCH PANEL

24 COER ODF Fiber Optic PATCH PANEL


  • Type: Fiber optic patch panel
  • Brand Name: Telsto/OEM
  • Fiber adapter: Fc/upc
  • Fiber connector: SC FC LC ST
  • Application: Telecommunication
  • Origin: Shanghai
  • Description

    Telsto series optical fiber terminal box can be applied in the branch connection of fiber termination, working as distribution box,19" standard structure, rack mounting, available for the installation of FC, SC, ST, LC adaptors.

    Feature

    ● All property indexes are in accordance with National YD/T925—1997 Standard.
    ● The body make use of cold rolling steel sheet Strong adhesive force, artistic and durable.
    ● Distinctive design of 1-2 cable entrance and fiber exit of 1-24 cores assures flexibility.
    ● Cable entrance are sealed with oil resistance NBR to increase the flexibility. Users can choose to prick the entrance and exit.
    ● Overlapping fiber-melting tray and separate insulation earth unit make the disposition of the cores, expanding the capacity and cable-earthen flexible, convenient and safe.

    1701162688086

    Technical Specifications

    ● External Size: (length×width×height) 430x240x1U/2U
    ● Optical fiber winding radius: ≥40mm
    ● Extra loss of fiber tray:none
    ● Fiber length left in tray:≥1.6m
    ● Fiber capacity: 48 cores
    ● Working temperature: - 400C ~ + 600C
    ● Lateral pressure-resistance: 500N
    ● Shock-resistance: 750N

    Order Guide

    Type Dimension(mm) Max capacity cores Remark
    Telsto-SC24 430*240*1U 24 Available for FC, ST, SC, LC .
    Telsto-SC48 430*240*2U 48



    Packing Information

    Type Inner carton dimension/ weight Outside carton dimension/ weight No./ carton
    Telsto -SC24 465*285*75mm/ 2.6kg 485*425*305/ 14.2kg

    5

    Telsto -SC48 465*285*125mm/ 3.8kg 675*485*305/ 21kg
