200G QSFP56 SR4 Active Optical Cable

Product Details: 200G QSFP56 SR4 Active Optical Cable (AOC)

Product Name: 200G QSFP56 SR4 Active Optical Cable

Type: Active Optical Cable (AOC)

Interface Type: Quad Small Form-Factor Pluggable 56 (QSFP56)

Data Rate: 200 Gigabit per Second (Gbps) Technology: Short Reach (SR4)

Operating Wavelength: 850 Nanometers (NM)

Length: Various Lengths Available (e.g., 1m, 3m, 5m, 7m, etc.)

Fiber Type: Multi-Mode Fiber (MMF)

Connector Type: QSFP56 Connectors at Both Ends

Place of Origin: Shanghai, China (Mainland)

Brand Name: Telsto

Send email to us

Description

200G QSFP56 SR4 Active Optical Cable

The 200G QSFP56 active optical cable is designed for use in 200 Gigabit Ethernet links over OM3 multimode fiber, it contains four multi-mode fibers (MMF) optic transceivers per end, each operating at data rates of up to 50Gb/s. This active optical cable is compliant with IEEE 802.3, SFF-8665, SFF-8636, QSFP56 MSA and InfiniBand HDR.

Max. Power Consumption 4.5W

Tested in Targeted Switches for Superior Performance, Quality, and Reliability

Minimum Bend Radius 30mm for Flexible Routing

Support InfiniBand HDR

Simplifies the Patching and Offers a Cost-effective Way for Short Links

High-speed Electrical Compliant to IEEE 802.3bs

4x 50G PAM4 Retimed 200GAUI-4 Electrical Interface

Hot Pluggable QSFP56 MSA Compliant

Class 1 Laser Safety

Specifications

Data Rate	200G
Form Factor	QSFP56
Model	SR4
Wavelength	850NM
Reach	100M
TX	VCSEL
RX	PIN
Cable Type	OM3
Cable Length	1M
Temperature	C Temp
