12 Core Fiber Optic Termination Box

12 Core Fiber Optic Termination Box


  • Type: 12 core fiber optic distribution box
  • Brand Name: Telsto
  • Use: FTTH
  • Fiber count: 12 Cores
  • Product name: 12 Cores Fiber Distribution Box
  • Color: Gray
  • Material: PC+ABS
  • Application: FTTH FTTB FTTX Network
  • Connector Type: UPC/APC
  • Origin: Shanghai
  • Description

    This box is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system.



    It integrates fiber splicing, splitting, distribution, storage and cable connection in one unit. Meanwhile, it provides solid protection and management for the FTTx network building.

    Feature

    Total enclosed structure, be in nice shape Clamping for feeder cable and drop cable, fiber splicing, fixation,
     Protects and manages cable effectively storage, distribution...etc all in one
     Secured with anti-theft locking mechanism Suitable for SC and LC duplex adaptor and pigtail
    Standard size, light weight Easy to operate
    High quality PC +ABS material Wall and pole mountable (accessories optional)
    Good properties of dust, and moisture proofing, IP65  Suitable for both outdoor and indoor use

    Application

    ● Telecommunication subscriber loop
    ● Fiber to the home(FTTH)
    ● LAN/WAN

    1701162248780

    Technical Data

    Work Temperature -40 ⁰C ~+85 ⁰C
    Relative Humidity ≤ 85% (+30 ⁰C)
    Atmospheric Pressure 70Kpa~106Kpa
    Insert Loss ≤ 0.2dB
    UPC Return Loss ≥ 50dB
    APC Return Loss ≥ 60dB
    Insert and Pull out Life ≥ 1000 times
    Insulation The grounding device is insulated with the Termination box, IR ≥1000m Ω/500V (direct current)
    Withstand Voltage Between the grounding device and the box body, the withstand voltage is over 3000V/ Min, no

    Breakdown and flashover. U ≥3000V (direct current)



    Dimensions

    Installation Dimensions

    225mm x 200mm x 65mm (AxBxC)

    168mm x 210mm (AxB)
