100G QSFP28 SR4 150M MPO MMF
100G QSFP28 SR4 150M MPO MMF
QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 100m over OM4 multimode fiber (MMF) using a wavelength of 850nm via a MTP/MPO-12 connector. This transceiver is compliant with IEEE 802.3bm 100GBASE-SR4 and CAUI-4 standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP28 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core and distribution layer applications.
Built-in Macom Chip, and Max. Power Consumption 2.5W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
High-Speed Electrical Interface Compliant to IEEE 802.3bm
Support 100G to 4x25G Breakout Application
Support Real-time Configuration
Hot Pluggable QSFP28 MSA Compliant
Class 1 FDA Laser Safety and RoHS Compliant
Digital Optical Monitoring Capability for Strong Diagnostic Capabilities
Specifications
|
Data Rate |
100GB |
|
Module |
SR4 |
|
Form Factor |
QSFP28 |
|
Wavelength |
850NM |
|
Reach |
150M |
|
Connector |
MPO |
|
Media |
MMF |
|
TX |
VCSEL |
|
RX |
PIN |
|
Temperature |
C Temp |
